Performances and Features:
1. The machine adopt Siemens,Germany PL C system to control the cutting length with auto counting and alarming stop function.
2. Unwinder adopts auto loading system and equipped with web guiding system.
3. Rewinding part is controlled by servo motor ensure machine running stable in high speed，and can be cut into2-5 rolls at the same time.
4. Machine comes with slitting function (blade/circular knife) and equipped with trim reject fan to remove the slit edge of web
5. Rewinder adopts Hydraulic Auto unloading system that liberate the workforce
Scope of Application: The machine is suitable for slitting big jumbo roll materials, such as paper, double adhesive paper, straw paper, copper baord paper, white board, aluminum foil, PVC etc. The machine is widely apply to paper products processing industry, printing and packaging industry
Performances and Features:
1. The machine adopt Siemens,Germany PL C system to control the cutting length with auto counting and alarming stop function.
2. Unwinder adopts auto loading system and equipped with web guiding system.
3. Rewinding part is controlled by servo motor ensure machine running stable in high speed，and can be cut into2-5 rolls at the same time.
4. Machine comes with slitting function (blade/circular knife) and equipped with trim reject fan to remove the slit edge of web
5. Rewinder adopts Hydraulic Auto unloading system that liberate the workforce
Main Technical Parameters:
|
Model |
GW-FJ-1300 |
GW-FJ-1600 |
GW-FJ-1800 |
|
Max. Web Width |
1300mm |
1600mm |
1800mm |
|
Max. Unwinder Diameter |
￠1400mm |
￠1400mm |
￠1400mm |
|
Max. Rewinder Diameter |
￠1300mm |
￠1300mm |
￠1300mm |
|
Rewind number |
2-5 ROLL |
2-5 ROLL |
2-5 ROLL |
|
Slitting Speed |
30-400 m/min |
30-400 m/min |
30-400 m/min |
|
Precision of Slitting |
±0.2mm |
±0.2mm |
±0.2mm |
|
Cutting Thickness |
30-300g/m2 |
30-400g/m2 |
30-400g/m2 |
|
Total Power |
18kw |
18-25kw |
25kw |
|
Machine Weight |
3700kg |
4000kg |
5000kg |
|
Overall Dimension |
4200*2600*1650mm |
4200*2900*1650mm |
4200*3400*1650mm |
Performances and Features: 1. The machine adopt Siemens,Germany PL C system to control the cutting length with auto counting and alarming stop function. 2. Unwinder adopts auto loading system and equipped with web guiding system. 3. Rewinding part is controlled by servo motor ensure machine running stable in high speed，and can be cut into2-5 rolls at the same time. 4. Machine comes with slitting function (blade/circular knife) and equipped with trim reject fan to remove the slit edge of web 5. Rewinder adopts Hydraulic Auto unloading system that liberate the workforce
